them will display the currently set configuration
values, and allow you to modify them.
These configuration values are channel specific.
You will need to select each channel in turn and
configure them separately.
Notes:
- For quick configuration, the copy function
allows you to easily copy the settings of the
current channel to another channel.
Channel Name
Alphanumeric text field for setting the channel
name. This is useful for giving the channel an
easily remembered and/or location-specific
name.
You may input up to a maximum of:
5 characters
Notes:
- Channels 1 to 6 are Analog/AnalogHD
channels.
- Channel 7 and 8 are Digital IP camera
channel.
DEFAULT SETTINGS:
Channel 1 – set name as – CH1
Channel 2 – set name as – CH2
Channel 3 – set name as – CH3
Channel 4 – set name as – CH4
Channel 5 – set name as – CH5
Channel 6 – set name as – CH6
Channel 7 – set name as – CH7
Channel 8 – set name as – CH8
Enable
Checkbox – if selected, enables this channel for
inclusion into the mainstream recording.
DEFAULT SETTINGS:
For channels 1 to 8, only enable the channels
which actually have cameras connected. Please
note that the system will show a video loss
message on channels which are enabled, but
do not have a connected camera (i.e., no
incoming video stream).
Resolution
Drop-down list for selecting the resolution to
record the video on this channel (applicable to
channels 1 to 6:
CIF (352x240)
WCIF (464x240)
