HDMI jack Plug an HDMI cable into this jack and an
HDMI input jack on a TV or other A/V device.
HDMI carries a high-quality digital video
and digital audio signal.
IEEE 1394 port Plug IEEE 1394 (also known as Firewire
™
)
devices (such as a digital camcorder) into
this 6-pin IEEE 1394 port. For more
information, see “Installing a printer,
scanner, or other device” on page 30.
USB ports Plug USB (Universal Serial Bus) devices
(such as a USB printer, scanner, camera,
keyboard, or mouse) into these ports. For
more information, see “Installing a printer,
scanner, or other device” on page 30.
S/PDIF output jack Plug an optical cable from an amplifier or
entertainment system into this jack for
digital sound.
Microphone jack
(pink plug)
Plug a microphone into this jack.
Headphone/analog
speakers jack (green
plug)
-OR-
Front speakers jack
This jack is user configurable for one of the
following:
Headphone: Plug headphones or amplified
speakers into this jack (Default).
Stereo out: Plug your front left and right
speakers into this jack.
For more information, see “Configuring the
audio jacks” on page 30.
DVI port (optional) Connect a DVI cable to this optional port and
to a DVI-capable display.
Modem jack
(optional)
Plug a modem cable into this jack. For more
information, see “Connecting a dial-up
modem” on page 16.
Case cover
thumbscrew
Remove this screw before opening the case.
PS/2 mouse port Plug a PS/2 mouse into this port.
Monitor (VGA) port Plug a VGA (blue connector) monitor cable
into this port.
Component Icon Description
