CHAPTER 3: Replacing notebook components
116
2 If the notebook has wireless networking built in, unplug the wireless antennas by
following the steps in “Replacing the IEEE 802.11 wireless card” on page 63.
3 Remove the hard drive by following the steps in “Replacing the hard drive” on
page 69.
4 Remove the keyboard cover by following the steps in “Replacing the keyboard
cover” on page 76.
5 Remove the keyboard by following the steps in “Replacing the keyboard” on
page 79.
6 Remove the LCD assembly by following the steps in “Replacing the LCD assembly”
on page 91.
7 Remove the palm rest by following the steps in “Replacing the palm rest” on
page 104.
8 Remove the touchpad board by following the steps in “Replacing the touchpad
board” on page 108.
9 Remove the touchpad button board by following the steps in “Replacing the
touchpad button board” on page 112.
10 Remove the fingerprint reader from the notebook.
11 Place the new fingerprint reader into the notebook in the same orientation as the
old reader.
12 Replace the touchpad button board by following the steps in “Replacing the
touchpad button board” on page 112.
13 Replace the touchpad board by following the steps in “Replacing the touchpad
board” on page 108.
14 Replace the palm rest by following the steps in “Replacing the palm rest” on
page 104.
15 Replace the LCD assembly by following the steps in “Replacing the LCD assembly”
on page 91.
16 Replace the keyboard by following the steps in “Replacing the keyboard” on
page 79.
17 Replace the keyboard cover by following the steps in “Replacing the keyboard
cover” on page 76.
18 Replace the hard drive by following the steps in “Replacing the hard drive” on
page 69.
19 If the notebook has wireless networking built in, reconnect the wireless antennas
by following the steps in “Replacing the IEEE 802.11 wireless card” on page 63.
