CHAPTER 3: Replacing notebook components
76
Replacing the keyboard cover
Tools you need to complete this task:
v
Screws removed during this task:
To replace the keyboard cover:
1 Complete the steps in “Preparing the notebook” on page 55.
2 Remove the two keyboard cover screws from the inside of the battery
compartment.
3 Turn your notebook over so the top is facing up.
4 Open the LCD panel to the fully opened position.
5 Insert the small flat-blade screwdriver under each of the hinge covers and gently
pry them up.
Flat-blade driver Scribe or non-marring tool- OR -
Phillips #0 screwdriver
2 black M2.5×3
(Keyboard cover)
Screw
Screw
To Next Page
