www.gateway.com
85
Replacing the webcam
Tools you need to complete this task:
v
Screws removed during this task:
To replace the webcam:
1 Complete the steps in “Preparing the notebook” on page 55.
2 Remove the keyboard cover by following the steps in “Replacing the keyboard
cover” on page 76.
3 Open the LCD panel to the fully open position.
4 Remove the rubber inserts from the front of the LCD panel assembly.
Important
You can complete this procedure with the LCD panel assembly connected to
the notebook. LCD panel assembly shown removed from notebook for clarity.
Flat-blade driver Scribe or non-marring tool- OR -
Phillips #0 screwdriver
6 black M2.5×8 (LCD
front panel)
2 black M2×3 (Webcam)2 black M2.5×3
(Keyboard cover)
Insert
Insert
Insert
Insert
InsertInsert
To Next Page
