CHAPTER 3: Replacing notebook components
58
Replacing the main cooling assembly
Tools you need to complete this task:
v
Screws removed during this task:
Additional materials you need to complete this task:
• X-23-7762 thermal grease
To replace the main cooling assembly:
1 Complete the steps in “Preparing the notebook” on page 55.
2 Loosen the cooling assembly bay cover screws (these screws cannot be removed).
Phillips #0 screwdriver
4 black M2×5 (main
cooling assembly)
(Optional)
Cooling
assembly
bay
Screw
Screw
Screw
Screw
Screw
