3 Use the thumb notch to lift the memory bay cover, then remove it. Be careful not
to break off the tabs located on the end of the cover opposite the thumb notch.
4 If you are removing a module, gently press outward on the clip at each end of the
memory module until the module tilts upward.
5 Pull the memory module out of the slot.
6 Hold the new or replacement module at a 30-degree angle and press it into the
empty memory slot. This module is keyed so it can only be inserted in one direction.
If the module does not fit, make sure that the notch in the module lines up with
the tab in the memory bay.
7 Press the card down until it clicks into place.
8 Replace the memory bay cover, then tighten the cover screws.
Thumb notch
Clip
Clip
