CHAPTER 1: System specifications
18
Back
eSATA jack
(optional)
eSATA Connect an external SATA hard drive to this optional jack.
Monitor port Plug an analog VGA monitor or projector into this port.
Component Icon Description
Ventilation fan Helps cool internal components.
Warning: Do not work with the notebook resting on your lap.
If the air vents are blocked, the notebook may become hot
enough to harm your skin.
Caution: Do not block or insert objects into these slots. If these
slots are blocked, your notebook may overheat resulting in
unexpected shutdown or permanent damage to the notebook.
Caution: Provide adequate space around your notebook so air
vents are not obstructed. Do not use the notebook on a bed,
sofa, rug, or other similar surface.
Power connector Plug the AC adapter cable into this connector.
Modem jack
(optional)
Plug a dial-up modem cable into this optional jack.
Component Icon Description
Power connector
Modem jack
Ventilation fan
