CHAPTER 3: Replacing notebook components
128
Replacing the system board and VGA cooling
assembly
Tools you need to complete this task:
v
Additional materials you need to complete this task:
• X-23-7762 thermal grease
Screws removed during this task:
Flat-blade driver Scribe or non-marring tool- OR -
Phillips #0 screwdriver
2 black M2.5×3
(Keyboard cover)
2 black M2.5×8
(Hinge top)
1 black M2.5×5 (DVD
drive)
8 black M2.5×8 (Palm
rest-bottom)
6 black M2.5×8 (Palm
rest-top)
3 black M2.5×5 (Palm
rest-top)
1 black M2×3 (Palm
rest-top)
2 black M2.5×8 (Hinge
bottom)
2 black M2×3 (IEEE
802.11 wireless card)
4 black M2.5×3
(Keyboard)
1 long black (Keyboard)
4 black M2×5 (main
cooling assembly)
(Optional)
