CHAPTER 1: System specifications
10
Memory card reader
ExpressCard
Audio
Item Specification
Controller RTS5158
Cards supported Support 5-in-1 card reader (MMC, MS, MS-pro, SD, and xD)
Compliancy <Please Verify>
■
Complies to SDIO Host Interface Specification Rev 1.0
■
Supports MMC, MMCplus, SD Memory, and SDIO cards
■
SDIO Version 1.10 compliant with High-Speed Mode
■
SD Host Interface Specification v1.0
■
SD Host Interface Specification v2.0
■
SD HC (High Capacity SD memory card)
■
Supports SD memory card, with CPRM security
■
Complies to MultiMediaCard™ Version 4.0
■
Supports Memory Stick™ and MS PRO media cards
■
Supports xD-Picture™ card and SmartMedia™ cards
Item Specification
Controller <Please provide>
Supports card type Type 54
Number of slots One
Access location Right panel
Item Specification
Audio Controller SigmaTel STAC9205
Conexant CX2056-15Z
Audio onboard or optional Built-in
Mono or Stereo Stereo
Resolution
■
Ten DAC channels support 16/20/24-bit PCM format for 7.1 sound playback, plus 2
channels of independent stereo sound output (multiple streaming) through the front
panel output
■
Two stereo ADCs support 16/20/24-bit PCM format, one for stereo microphone, one for
legacy mixer recording
Compatibility
■
HD Audio
Sampling rate
■
All DACs supports 44.1/48/96/192 kHz sample rate
■
All ADCs support 44.1/48/96 kHz sample rate
■
Two independent 16/20/24-bit S/PDIF-OUT converters support 44.1/48/96/192 kHz
sample rate, one for nominal digital audio, the other one for digital audio output to HDMI
transmitter
Internal microphone With optional webcam
