www.gateway.com
59
3 Use the thumb notch to lift the cooling assembly bay cover, then remove it. Be
careful not to break off the tabs located on the end of the cover opposite the thumb
notch.
4 Loosen or remove the screws that secure the main cooling assembly to the system
board. Use the numbers stamped in the metal next to each screw and loosen the
screws in reverse numerical order (start with 5, then 4, then 3, then 2, then 1).
5 At the same time as you lift, move the main cooling assembly away from the side
of the notebook, then remove the main cooling assembly.
Important
Screws 1 - 4 may be captive and you may not be able to remove them.
Thumb notch
Screw 4
Screw 1
Screw 2
Screw 5
Screw 3
