CHAPTER 3: Replacing notebook components
122
2 If the notebook has wireless networking built in, unplug the wireless antennas by
following the steps in “Replacing the IEEE 802.11 wireless card” on page 63.
3 Remove the hard drive by following the instructions in “Replacing the hard drive”
on page 69.
4 Remove the keyboard cover by following the steps in “Replacing the keyboard
cover” on page 76.
5 Remove the keyboard by following the steps in “Replacing the keyboard” on
page 79.
6 Remove the LCD assembly by following the steps in “Replacing the LCD assembly”
on page 91.
7 Remove the palm rest by following the steps in “Replacing the palm rest” on
page 104.
8 Remove the screws that secure the modem to the notebook.
Screw
Screw
