CHAPTER 3: Replacing notebook components
126
2 If the notebook has wireless networking built in, unplug the wireless antennas by
following the steps in “Replacing the IEEE 802.11 wireless card” on page 63.
3 Remove the hard drive by following the instructions in “Replacing the hard drive”
on page 69.
4 Remove the keyboard cover by following the steps in “Replacing the keyboard
cover” on page 76.
5 Remove the keyboard by following the steps in “Replacing the keyboard” on
page 79.
6 Remove the LCD assembly by following the steps in “Replacing the LCD assembly”
on page 91.
7 Remove the palm rest by following the steps in “Replacing the palm rest” on
page 104.
8 Disconnect the old speaker cable from the system board.
9 Remove the speaker screws.
10 Lift the old speakers from the notebook.
11 Set the new speakers into the notebook, then replace the screws removed in Step 9.
12 Connect the cable to the system board.
13 Replace the palm rest by following the steps in “Replacing the palm rest” on
page 104.
14 Replace the LCD assembly by following the steps in “Replacing the LCD assembly”
on page 91.
Screw
Screw
Screw
To Next Page
