www.gateway.com
141
11 Remove the fan screws.
12 Lift the old fan from the notebook.
13 Set the new fan into the notebook, then replace the screws removed in Step 11.
14 Replace the system board by following the steps in “Replacing the system board
and VGA cooling assembly” on page 128.
15 Replace the palm rest by following the steps in “Replacing the palm rest” on
page 104.
16 Replace the LCD assembly by following the steps in “Replacing the LCD assembly”
on page 91.
17 Replace the keyboard by following the steps in “Replacing the keyboard” on
page 79.
18 Replace the keyboard cover by following the steps in “Replacing the keyboard cover”
on page 76.
19 Replace the DVD drive by following the steps in “Replacing the DVD drive” on
page 73.
20 Replace the hard drive by following the instructions in “Replacing the hard drive”
on page 69.
Screw
Screw
