www.gateway.com
65
5 Remove the wireless card screws.
6 Pull the card out of the slot.
7 Move the antenna cables out of the way.
8 Hold the new card at a 30-degree angle and slide it into the empty slot. This card
is keyed so it can only be inserted in one direction. If the card does not fit, make
sure that the notch in the card lines up with the tab in the card slot.
9 Replace the screws removed in Step 5.
10 Reattach the antenna cables to the connectors.
11 Replace the wireless bay cover, then tighten the cover screws.
Screw
Screw
