Introduction and Component
Overview
This Maintenance Guide provides step-by-step instructions for rep
lacing and maintaining the
components of the Puma Cutting plotter. It also includes a troubleshooting chapter
with some handy hints when problems arise or if the plotter does not operate properly.
This Maintenance Guide provides system diagrams, wiring diagrams and numerous flow
charts detailing the maintenance diagnostics built into the Expert Pro Cutting plotter.
Finally
there is a parts list and spare parts order form for convenience of ordering replacement parts.
For further Tech Support enquiries and assistance please contact the following Email
address:
Tech.support@gcc.com.tw
The following diagrams represent all of the maintainable mechanical and electronic
components of the Expert Pro Cutting Plotter with corresponding parts lists for
convenient identification.
