32
Replacing the Pinch Roller Sets
The
following steps are those involved in replacing pinch roller sets.
To Unlatch the Pinch Roller Lever:
1. Pull down the Square Bar Lever to
unlatch the Pinch Rollers
To Remove the Square Bar Holding Bra
cket:
2. Unscrew the 2 bracket screws.
3. Remove the bracket and washer.
To Next Page
