Check
Lever Sensor
Up/Down
Ente
Key
Diagnostic Test for SRAM and DRAM
This
test provides the ability to diagnose the SRAM and DRAM. If these two components are bad, replace them. Otherwise the
cutting plotter will not work properly.
Diagnostic
Test
for
Lever
Sensor
This
feature diagnoses the lever sensor. If the sensor is faulty, the cutting plotter cannot sense that the pinch rollers have
been lowered or not. If the lever sensor is down, you will see a lift the lever message on the LCM. If the lever is up, you will see
a lower the lever message on the LCM. You can use the ON/OFF LINE KEY to abort your test when y ou have finished
the lever sensor test.
Cancel Key
Display lever
sesor condition messages
Previous/Next Test item
Note
that: LCM will display one of following messages
1.Lower The Lever Please CANCEL
2.Lift The Lever Please CANCEL
The first message means that the current lever condition is up
The second messsage means the lever is down
