62 232001250G(06)
Without Home: The laser head will start the next job based on its position from its graphic application
software setting, from the last position of the previous job. Upon completion of the current job, the laser
head will remain at the last position of the previous job.
Relative: This mode sets the current laser head position to correspond to the origin (top left) position of
the graphic software. Therefore, the laser head will process the job from its current position relative to its
setting in the graphics software.
Center: Sets the current position of the laser head as the center point for your subsequent job. As an
example, if the subsequent job is to vector cut a circle and you have the Position Mode set to Center, then
the X380 will vector cut a circle around the initial position of the laser head.
TIP
It is highly recommended you enable the red dot laser pointer when setting / adjusting
the Position Modes, as this makes accurate positioning of your laser carriage for your
particular jobs much easier.
Vector Function (Advance Page)
[DEFAULT SETTING: Normal]
Normal: This selection will not apply any special advanced vector function to your job. This is the default
Vector Function setting.
Vector Sorting: When performing a vector cutting job in which your image has one vector cut area
enclosing within another vector cut area, select the vector sorting mode. This mode will automatically
instruct the print driver to process the inside vector image and moving outwards. If you try to process a
vector image that has multiple layers without using this mode, what may occur is the laser machine may
process the outer vector cutting first, and any inner vector cutting will not be possible as your centerpiece
material may have dropped to the cutting table. This setting will always automatically direct the laser to cut
from the inner most vector shape and move outwards.
Optimization Sorting: This is a setting that will minimize your process time. When selected, the print
driver will analyze your image and automatically determine the most efficient processing path to process
your image.
Enhanced Vector Mode (Advance Page)
[DEFAULT SETTING: Unselected]
This setting allows you to improve the cutting quality at the expense of speed. We recommend you enable this
function when cutting thicker materials.
