a) Under Paper Size, the X value represents the length of your working piece.
Enter the
length of your work piece in this field.
b) UUnnddeerr PPaappeerr SSiizzee,, tthhee DDiiaammeetteerr vvaalluuee rreepprreesseennttss tthhee ddiiaammeetteerr ooff yyoouurr wwoorrkkiinngg
ppiieeccee
(at the position you wish to engrave). Enter the diameter of your work piece in
this field. Again remember the proper diameter value would be the diameter
location on your work piece you will be engraving.
c) Under Rotary Parameter, the Offset value represents distance from the open end
of your work piece to the base of the padded rubber wheel. This value will be
displayed on the Spirit’s LCD panel. Enter the proper offset value in this field.
5) Your Spirit print driver settings are now properly set. Manually position the laser
carriage to the
proper X / Y location on the object you will be engraving and position the auto focus
pin over the area to be engraved on your work piece. Hit the Auto Focus button and
the Spirit will now
properly focus at the location to be engraved.
6) Go back to the Spirit Print Driver to print your design and let the engraving begin.
7) Despite the dummy-proof installation design, please ensure that the device is installed
correctly before turning on the machine
NOTE
The maximum diameter and length of the to-be-engraved object is 180 mm and
450 mm respectively. Its maximum weight should not exceed 4 kg.
Chapter VIII Basic Maintenance
Keeping your LaserPro X380 clean and well maintained will ensure quality output, consistent reliability,
and extended product life. Smoke, dust or residue build-up inside the laser system or the mechanical
components can cause a reduction in the laser power, irregularities in the motion system, reduced
product life cycle, and a host of other avoidable problems. This section will cover how to perform regular
maintenance on the X380’s worktable, motion system, mirrors, and focal lens.
The frequency of the cleaning schedule will depend on number of variables such as the types of material
you work with, the immediate work environment, the frequency of use, the quality of the exhaust system,
etc.
WARNING
 Electrical Shock may occur if you do not turn off and unplug the X380 before
cleaning.
 Damage may occur to the system if you do not turn off and unplug the X380
before cleaning.
 Always turn off and unplug the X380 before cleaning!
