GE Agile P50 Series - 2.12.11 VIEW RECORDS

7 Protection Parameter Settings
P50 Agile P153
7-22
P153/EN M/B
Sr. No
Parameter
Defaults setting
Setting / Ranges
2. CB Fail Timer 0.1 S 0s to 50s step 0.01s
This setting sets the time delay in which the CB opening must be detected.
3. CBF Reset CB Open + I<
1=I< Only
2=CB Open + I<
3=Prot Reset + I<
4= CB Open
This setting determines the elements that will reset the CB fail timer for CB Failures
4. I< 1.00*In 0.05*In to 3.20*In step 0.01
This setting determines the current threshold, which will reset the CB Fail timer for Overcurrent based protection
5. IN< 1.00*In 0.05*In to 3.20*In step 0.01
This setting determines the current threshold, which will reset the CB Fail timer for Earth fault based protection
6.
Remove I> Start
Disabled
Disabled / Enabled
This setting for removing phase overcurrent start signal following CBF operation
7. Remove IN> Start Disabled Disabled / Enabled
This setting for removing earth overcurrent start signal following CBF operation
2.12.11 VIEW RECORDS
Sr. No
Parameter
Display value on LCD
1. Fault Record Display the Records of fault i.e. parameter value, flag of fault & date and time of Fault
2.
Event Record
Display of all digital events with time stamping (max 512 events)
3.
Maint Record
Display of error generated by relay if any, in case of failure of hardware
4. Alarm Record Display of alarm generated by relay & date and time of generated alarm.
