12 SCADA Communications
P50 Agile P153
9-8
P153/EN M/B
IN1 2 32 bit Float R 33287 – 33288
Th State 2 32 bit Float R 33289 – 33290
IN2
2
32 bit Float
R
33291 – 33292
I2
2
32 bit Float
R
33293 – 33294
I1 2 32 bit Float R 33295 – 33296
I2/I1 2 32 bit Float R 33297 – 33298
TC 2 32 bit Float R 33305– 33306
BOC 2 32 bit Float R 33307– 33308
BOT
2
32 bit Float
R
33309– 33310
Sr.No.
Function
Code
Register
No.
of
Regs
Format
Reg.
Type
Address Map
7 Fault Data 04
Fault DUR
2
32 bit Float
R
35401– 35402
Fault L1 Value
2
32 bit Float
R
35403– 35404
Fault L2 Value 2 32 bit Float R 35405– 35406
Fault L3 Value 2 32 bit Float R 35407– 35408
Fault IN1
Value
2 32 bit Float R 35409– 35410
2.2 IEC60-870-5-103
2.2.1 Overview
The specification IEC 60870-5-103 (Telecontrol Equipment and Systems Part 5 Section 103:
Transmission Protocols), defines the use of standards IEC 60870-5-1 to IEC 60870-5-5, which were
designed for communication with protection equipment.
This section describes how the IEC 60870-5-103 standard is applied to the P153 relay. It is not a
description of the standard itself. The level at which this section is written assumes that the reader is
already familiar with the IEC 60870-5-103 standard.
This section should provide sufficient detail to enable understanding of the standard at a level required
by most users.
The IEC 60870-5-103 interface is a master/slave interface with the device as the slave device. The
device conforms to compatibility level 2, as defined in the IEC 60870-5-103.standard.
The following IEC 60870-5-103 facilities are supported by this interface:
• Initialization (reset)
• Time synchronisation
• Event record extraction
• General interrogation
• Cyclic measurements
• General commands
• Disturbance record extraction
