GE Agile P50 Series User Manual

P50 Agile P153
9 SCADA Communications
P153/EN M/B
9-9
2.2.2 Physical Connection and Link Layer
There are two options available for connecting on IEC 60870-5-103:
• Front USB port
• Rear serial port 1- for permanent SCADA connection via RS485
The IED address and baud rate can be selected using the front panel menu or with P50 Agile
configurator.
2.2.3 Initialisation
Whenever the device has been powered up, or if the communication parameters have been changed,
a reset command is required to initialize the communications. The device will respond to either of the
two reset commands; Reset CU or Reset FCB (Communication Unit or Frame Count Bit). The
difference between the two commands is that the Reset CU command will clear any unsent messages
in the transmit buffer, whereas the Reset FCB command does not delete any messages.
The device will respond to the reset command with an identification message ASDU 5. The Cause of
Transmission (COT) of this response will be either Reset CU or Reset FCB depending on the nature of
the reset command.
The relay will also produce a power up event, when the relay is powered up.
2.2.4 Time Synchronisation
The time and date can be set using the time synchronisation feature of the IEC 60870-5-103 protocol.
The device will correct the transmission delay depending on communication speed. For this,
transmission time, required for the time synchronization frame from the Master to IED, considering
current baud rate is added in the received time.
The device will correct the transmission delay depending on baud rate. If the time synchronisation
message is sent as a send/confirm message then the device will respond with a confirm message. A
time synchronisation Class 1 event will be generated/produced whether the time-synchronisation
message is sent as a send confirm or a broadcast (send/no reply) message.
2.2.5 Spontaneous Events
Events are categorized using the following information:
• Function type
• Information Number
The IEC 60870-5-103 profile contains a complete listing of all events produced by the device.
2.2.6 General Interrogation (GI)
The GI request can be used to read the status of the device, the function numbers, and information
numbers that will be returned during the GI cycle. These are shown in the IEC 60870-5-103 profile.
2.2.7 Cyclic Measurements
The device will produce measured values using ASDU9 and ASDU9 is reported with information
number 148 and 155. This can be read from the device using a Class 2 poll. For every query, the
current online data is reported.
The device transmits its measurands at 2.4 times the rated value of the analogue value.
