P50 Agile P153
5 Configuration
P153/EN M/B
5-52
Thermal Alarm
70%
Editable setting
By using the (5) or (6) key, Thermal Alarm can be set. The setting
range is from 50% to 100% in steps of 1%.
Time Constant 1
10
Editable setting
By using the (5) or (6) key, Time Constant 1 can be set. The setting
range is from 1 to 200 in steps of 1.
K
1.05
Editable setting
By using the (5) or (6) key, K Constant can be set. The setting range
is from 1 to 1.5 in steps of 0.01.
2.3.16.9 Group1 – Cold Load Pickup Submenu
2.3.16.9.1
Edit Settings
GROUP 1
Password protected window for “GROUP 1’’ settings:
SYSTEM CONFIG, OVERCURRENT, NEG SEQUENCE O/C, BROKEN
CONDUCTOR, EARTH FAULT 1, EARTH FAULT 2, THERMAL
OVERLOAD, COLD LOAD PICKUP, UNDERCURRENT and CB FAIL.
Note: Group 1 Setting will be seen only when it is enabled in
Configuration setting..
COLD LOAD PKP
Password protected window for Cold Load Pickup i.e. tcold Time Delay,
tclp Time Delay, I>1 Status, I>2 Status, I>3 Status, IN1>1 Status, IN1>2
Status, IN1>3 Status, IN2>1 Status, IN2>2 Status and IN2>3 Status.
tcold Time Delay
7200 S
Editable setting
By using the (5) or (6) key, tcold Time Delay can be set. The setting
range is from 0 to 14400s in steps of 1s.
tclp Time Delay
7200 S
Editable setting
By using the (5) or (6) key, tclp Time Delay can be set. The setting
range is from 0 to 14400s in steps of 1s.
I>1 Status
Enabled
Editable setting
By using the (5) or (6) key, I>1 Status can be Enabled / Blocked.
I>2 Status
Enabled
Editable setting
By using the (5) or (6) key, I>2 Status can be Enabled / Blocked.
