GE Agile P50 Series - 2.3.4.2 View Fault Records

P50 Agile P153
5 Configuration
P153/EN M/B
5-13
Alarm Record
This window is to view the
Alarm Record
2.3.4.2 View Fault Records
VIEW RECORDS
This menu is to view Fault Record, Event Record, Maint Record and
Alarm record.
Fault Record
This window shows the Fault Record
Fault Num = 01
This window shows the Fault Number of latest fault.
I>1: I<:
IN1>1: IN2>1: I2>1:
This window will show trip flag of stage 1: O/C, E/F-1 and E/F-2, Neg
Sequence O/C, Under Current, Thermal Trip.
Note: This window is seen when relay operates for respective protection
function. `
I>2:
IN1>2: IN2>2: I2>2:
This window will show trip flag of stage 2: O/C, E/F-1 and E/F-2, Neg
Sequence O/C.
Note: This window is seen when relay operates for respective protection
function.
I>3:
IN1>3: IN2>3: I2>3:
This window will show trip flag of stage 3: O/C, E/F-1 and E/F-2, Neg
Sequence O/C.
Note: This window is seen when relay operates for respective protection
function.
S1 S2 S3 S4
CLP BC CBF TH EXT TR
This window will show status flag (S1 – Opto Input 1, S2 – Opto Input 2,
S3 – Opto Input 3, S4 – Opto Input 4, CLP – Cold Load Pickup, BC –
Broken Conductor, CBF – CB Fail, TH – Thermal Trip, EXT TR –
External Trip).
Note: This window is seen when status flag operates
ia = 0.00 A
ib = 0.00 A
This window will show secondary fault current values.
