COLD LOAD PKP
Password protected window for Cold Load Pickup i.e. tcold Time Delay,
tclp Time Delay, I>1 Status, I>2 Status, I>3 Status, IN1>1 Status, IN1>2
Status, IN1>3 Status, IN2>1 Status, IN2>2 Status and IN2>3 Status.
tcold Time Delay
7200 S
Editable setting
By using the (5) or (6) key, tcold Time Delay can be set. The setting
range is from 0 to 14400s in steps of 1s.
tclp Time Delay
7200 S
By using the (5) or (6) key, tclp Time Delay can be set. The setting
range is from 0 to 14400s in steps of 1s.
I>1 Status
Enabled
Editable setting
By using the (5) or (6) key, I>1 Status can be Enabled / Blocked.
I>1 Current Set
1.50 A
Editable setting
By using the (5) or (6) key, I>1 Current Set can be set. The setting
range is from 0.05 to 4.00 In in steps of 0.01 In.
I>1 Time Delay
0.01 S
By using the (5) or (6) key, I>1 Time Delay can be set. The setting
range is from 0 to 100s in steps of 0.01s.
NotE: The settings of I>2 Status, I>3 Status, IN1>1 Status, IN1>2 Status, IN1>3 Status, IN2>1 Status,
IN2>2 Status, IN2>3 Status can be set in a similar manner as that of I>1 Status.
2.3.16.10 Group1 –Undercurrent Submenu
2.3.16.10.1
Edit Settings
(If I< Status is disabled)
GROUP 1
Password protected window for “GROUP 1’’ settings:
SYSTEM CONFIG, OVERCURRENT, NEG SEQUENCE O/C, BROKEN
CONDUCTOR, EARTH FAULT 1, EARTH FAULT 2, THERMAL
OVERLOAD, COLD LOAD PICKUP, UNDERCURRENT and CB FAIL.
Note: Group 1 Setting will be seen only when it is enabled in
Configuration setting.
UNDERCURRENT
Password protected window for
i.e. I< Status, I< and tI<.
