GE Agile P50 Series User Manual

P50 Agile P153
9 SCADA Communications
P153/EN M/B
9-7
Sr. No. Function
Code
Register No.
of
Regs
Format Reg.
Type
Address Map
Trip IN1>3
1
1 bit
R
12808
Trip IN2>1 1 1 bit R 12809
Trip IN2>2 1 1 bit R 12810
Trip IN2>3
1
1 bit
R
12811
Trip BC
1
1 bit
R
12812
THOL Trip 1 1 bit R 12813
CLP 1 1 bit R 12814
Trip I<
1
1 bit
R
12815
Trip CBF 1 1 bit R 12816
Ext Trip 1 1 bit R 12817
CBOpr Alm 1 1 bit R 12818
Opto I/P 1
1
1 bit
R
12819
Opto I/P 2 1 1 bit R 12820
Opto I/P 3 1 1 bit R 12821
Opto I/P 4 1 1 bit R 12822
TCS Alarm
1
1 bit
R
12825
Trip LED
1
1 bit
R
12826
CBOpn Sup 1 1 bit R 12827
BC Alarm 1 1 bit R 12828
Sr.No. Function
Code
Register No.
of
Regs
Format Reg.
Type
Address Map
5 Outputs 05
LED Reset 1 16 bit W 03025
Trip 1 16 bit W 03026
Close 1 16 bit W 03027
Output 1
1
16 bit
W
03028
Output 2
1
16 bit
W
03029
Output 3 1 16 bit W 03030
Output 4 1 16 bit W 03031
Sr.No. Function
Code
Register No.
of
Regs
Format Reg.
Type
Address Map
6
Parameters
04
IL1
2
32 bit Float
R
33281– 33282
IL2 2 32 bit Float R 33283– 33284
IL3 2 32 bit Float R 33285 – 33286
