12 SCADA Communications
P50 Agile P153
9-12
P153/EN M/B
Sr. No. INF Description GI TYP COT FUN
121 Trip IN2>3 - 2 1,7 126
9
Trip BC
-
2
1,7
124
202
THOL Trip
-
2
1,7
126
225 CLP - 2 1,7 126
177 Trip I< - 2 1,7 126
85 CBF Trip - 2 1,7 160
2 Ext Trip - 2 1,7 124
1
CBOpn Sup
-
2
1,7
124
3
BC Alarm
-
2
1,7
124
Sr. No. INF Description GI TYP COT FUN
5 Semantics of INFORMATION NUMBER: Measurands in monitor direction
148 Measurand I
L 1,2,3
- 9 2, 7 160
155
IN1, Th State, IN2, I2, I1, I2/I1
ratio
-
9
2,7
160
1 Trip Counter, Breaker
Operation Counter, Breaker
Operating Time
- 244 2,7 127
Note: The measurands transmitted by the relay are sent as a proportion of 2.4 times of the rated value of
the analogue value.
Sr.
No.
INF
Description
GI
TYP
COT
FUN
6
Semantics of INFORMATION NUMBER: Fault list in monitor direction
0
List of Recorded DR
-
23
31
160
Sr. No. INF Description
7 Semantics of Actual Channel: Used for DR Transmission
ACC
Description
1
IL1 - Primary
2
IL2
3 IL3
4 IN2 (Derived)
74 IN1 (Measured)
Sr. No.
INF
Description
GI
TYP
COT
FUN
8 Semantics of INFORMATION NUMBER : System Functions in control direction
0 Initialization of general interrogation - 7 9 255
0 Time synchronization - 6 8 255
Sr. No. INF Description GI TYP COT FUN
9
Semantics of INFORMATION NUMBER: General commands in control direction
19
LED Reset
ON
20
20
160
124 Trip ON/OFF 20 20 127
