1 Introduction
P50 Agile P153
1-6
P153/EN M/B
ANSI FUNCTION P153
86 Latching of output contacts (Lockout)
•
Control Functions
74 Trip circuit supervision
•
Watchdog function
•
Self monitoring & diagnostics
•
Test/Commissioning facilities
•
HMI
Back-Lit LCD display
•
6 x Touch Keys
•
6 x status LEDs
•
Communication
USB port
•
Modbus/IEC 60870-5-103
•
Binary Input/Output
Binary Input
4 (ungrouped)
Binary Output
4 (2NO+2C/O)
Analogue Input
Phase current input 3x1 ph
•
Earth current input 1x1 ph
•
General
Setting Groups 2
Self diagnostics
•
Measurements
•
Event records
•
Fault records
•
Disturbance records
•
Configurable BI/BO/LEDs
•
Hardware
Auxiliary supply 24-50V DC or 110-230 V AC/DC
Climatic conditions
Operating :
-25
o
C to +55
o
C
Storage :
-25
o
C to +70
o
C
Housing
Front IP 52
Rear IP 20
