NoteFunction (qty)Tag

Column 1 bottom connectionC1B

Part of column 2 optionColumn 2 top connectionC2T

Part of column 2 optionColumn 2 bottom connectionC2B

CIP inletsCIP1 to CIP4

CIP common inletCIP C

OptionFilterFH-231

Part of filter option, manualFilter vent valveHV-301

Capsule filter option onlyCapsule filter bottom manual

valve

HV-302

Capsule filter option onlyCapsule filter top manual valveHV-303

Part of sample pump optionSample inletsM1, M2

System pump AP-201 A

OptionSystem pump BP-201 B

OptionSample pumpP-202

OptionPressure control valve, A inletsPCV-341

OptionPressure control valve, B inletsPCV-342

Common wasteW

Buffer A inlet valvesXV-001, XV-002

OptionalBuffer A inlet valvesXV-003 to XV-010

Part of system pump B optionBuffer B inlet valvesXV-011 to XV-016

Part of sample pump optionSample connection valveXV-017

Part of sample pump optionSample inlets valvesXV-018, XV-019

Air trap inlet valveXV-021

Air trap bypass valveXV-022

Air trap vent valveXV-023

Air trap outlet valveXV-024

Part of filter optionFilter inlet valveXV-025

74 ÄKTAprocess Operating Instructions 29-0252-49 AA

3 System description

3.5 Flowchart
