Revision C 170 Series Monitor 7-9

2000947-004

Serviceable Assemblies: Transducer Plug Replacement Kits

Table 7-4. Ultrasound Cable Wiring

Pin Number Pin Length Description Wire Color

1 short — —

2 short — —

3 short Overall Shield #24 AWG Green

4 LONG US Transmit/Receive Shield #24 AWG Green

5 short White Coax —

6 short — —

7 short — —

8 short — —

9 short — —

10 short — —

11 short US Enable #24 AWG Green Jumper

12 short US Enable Ground #24 AWG Green Jumper
