Revision C 170 Series Monitor 2-5
2000947-004
Introduction: About Your Monitor
About Your Monitor
This manual describes all monitors in the 170 Series; therefore some sections may
not apply to your model monitor. Refer to Table 2-1.
Model 171
The Model 171 Antepartum Fetal Monitor provides singleton ultrasound and
external uterine activity monitoring.
Model 172
The Model 172 Antepartum Fetal Monitor provides dual ultrasound and external
uterine activity monitoring.
Model 173
The Model 173 Intrapartum Monitor provides dual heart rate monitoring using
FECG and ultrasound. The monitor also provides external uterine activity
monitoring using a tocotransducer or internal monitoring using an intrauterine
pressure catheter (IUPC).
Model 174
The Model 174 Intrapartum Monitor provides dual heart rate monitoring using
FECG/ultrasound or dual ultrasound. The monitor also provides external uterine
activity monitoring using a tocotransducer or internal monitoring using an IUPC.
Table 2-1. Summary of Features
Feature 171 172 173 174
External uterine activity (TOCO) 9999
Internal uterine activity (IUPC) 99
Ultrasound
a
9999
Dual ultrasound 99
FECG
a
99
Fetal heart rate alarms 9999
Fetal movement detection (optional) 9999
Heartbeat coincidence 999
Fetal heart rate offset 999
a
The Model 174 has a combi-connector for the primary FHR that can be used for either US or FECG.
