Revision C 170 Series Monitor 7-1
2000947-004
Chapter 7
Serviceable Assemblies7
This chapter provides information to aid in performing routine service and
maintenance on a 170 Series Monitor. This section of the manual is not intended as
a substitute for proper professional training, or familiarity with the 170 Series
Monitor. Only qualified service personnel should attempt servicing a 170 Series
Monitor.
This chapter contains the following information:
General Anti-Static Handling Precautions . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Transducer Plug Replacement Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Nautilus Transducer Cable Replacement . . . . . . . . . . . . . . . . . . . . . . . . 7-15
Removing the Monitor Top Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-19
Tocotransducer Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-20
Nautilus Ultrasound Transducer Top Cover Replacement . . . . . . . . . . 7-30
Nautilus Transducer Reassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-32
Testing a Repaired Transducer (TOCO or US) . . . . . . . . . . . . . . . . . . . 7-34
Replacing the Main Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-35
Replacing the Membrane Switch Panel . . . . . . . . . . . . . . . . . . . . . . . . . 7-37
Replacing a Front Panel Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-40
Servicing the Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-41
