7-30 170 Series Monitor Revision C
2000947-004
Serviceable Assemblies: Nautilus Ultrasound Transducer Top Cover Replacement
Nautilus Ultrasound Transducer Top Cover
Replacement
In order to replace the top cover of a Nautilus Ultrasound Transducer in the field,
you will require one of two kits. Refer to Table 7-11 and ensure you have the correct
kit. Unpack the kit and ensure it contains the items listed in Table 7-12. If
something is missing, contact your GE Service Representative immediately. The
text of the instruction sheet is repeated here for informational purposes.
.
Equipment Required
You will need the following equipment:
Phillips Head Torque Driver
Loctite Adhesive #454 (recommended)
Anti-Static Wristband
Static-Free Work Surface
Table 7-11. Kit Summary
Nautilus Ultrasound Transducer
Type and Cat. No. (REF)
Cable Kit
Cat. No. (REF)
Loop-Style Ultrasound Transducer, 5700 KAX/LAX/MAX 2011679-001
Button-Style Ultrasound Transducer, 5700GAX/HAX/JAX 2011680-001
Table 7-12. Packing List
Item Qty
Transducer Case Top 1
Flat-Seal O-Ring 1
Sealing Screw, #4-40 x 5/16 in 6
Screw Cap, Curved 4
Screw Cap, Flat 1
Belt Knob
a
a
The belt knob is included in button-style
kits 2011680-001 only.
Screw Cap Extraction Tool 1
