Parts Lists: 1509AAO/BAO, Qwik Connect Plus Legplate Assembly Parts List
1509AAO/BAO, Qwik Connect Plus Legplate
Assembly Parts List
Table 11-9. 1509AAO/BAO, Qwik Connect Plus Legplate Assembly Parts List
Find
Num
Item Number Item Description Qty
1 2000532-001 CABLE STRAIN RELIEF 8 FEET 1
2 210227 CONTACT,MALE,24AWG,16.5MM,LG 11
3 210180 HALF-SHELL,W/CLAMP,3-5MM 1
4 210181 CLAMP,3-7MM 1
5 210176 RING 1
6 210183 GRIPPER,3-5MM 1
7 210182 SCREW,CLAMP,M 2.6 X 10 2
8 608048 SHRINK TUBING,1/4 BLK, .021
9 605105 WIRE,#24 STRANDED,GRN, .125
10 210179 HALF-SHELL,W/TONGUE 1
11 210178 RING,PLASTIC,21.8 X4 1
12 212133 PLUG,12 CKT GREY/BRN,A-D, 1
13 210226 CONTACT,MALE,24AWG,18MM L,G 1
14 2000528-001 COVER INTERFACE CABLE 1
15 2002641-001 O-RING .101 ID, .070THK, 70DUR, SILICONE 1
16 2000529-001 PIN COAX RECEPTACLE 1
17 2000527-001 CABLE BASE INTERFACE 1
18 2000429-003 PCB LEG PLATE BD 1
19 2000208-001 SPRING WIRE,LEG PLATE SNAP .125 STUD 1
20 440011 LABEL,2.25X.75,SELF-LAM,WHITE 1
22 2000595-001 LABEL SHIPPING FOR 1590AAO 1
23 410112 BAG,AIRCAP, 6 X 8-1/2 1
24 605106 WIRE,#24 STRANDED,BLUE .083
25 2002357-001 SPACER SPRING QWIK CONNECT PLUS 1
26 13658AA LABEL,CE MARK-ACCESSORIES,WATERPROOF 1
