Revision C 170 Series Monitor 7-15
2000947-004
Serviceable Assemblies: Nautilus Transducer Cable Replacement
Nautilus Transducer Cable Replacement
You can replace the cable on a Nautilus Tocotransducer or Ultrasound Transducer
using one of four kits. Refer to Table 7-6 and ensure you have the correct kit. The
text of the instruction sheet is repeated here for informational purposes. Unpack the
kit and ensure it contains the items listed in Table 7-7. If something is missing,
contact your GE Service Representative immediately.
NOTE: Transducers are available in 5-, 8-, and 10-foot cable lengths. However, the
cable assembly included in a replacement kit is available in an 8-foot
length only.
Table 7-6. Kit Summary
Nautilus Transducer
Type and Cat. No. (REF)
Cable Kit
Cat. No. (REF)
Loop-Style Ultrasound Transducer, 5700 KAX/LAX/MAX 2003659-001
Button-Style Ultrasound Transducer, 5700 GAX/HAX/JAX 2003660-001
Loop-Style Tocotransducer, 2264 DAX/EAX/FAX/KAX/LAX/MAX 2003661-001
Button-Style Tocotransducer, 2264 AAX/BAX/CAX/GAX/HAX/JAX 2003662-001
Table 7-7. Packing List
Item Qty
Transducer Case Top 1
Cable Assembly, 8-ft 1
Flat-Seal O-Ring 1
Sealing Screw, #4-40 x 5/16 in 6
Screw Cap, Curved 4
Screw Cap, Flat 1
Belt Knob
a
a
The belt knob is included in button-style
kits 2003660-001 and 2003662-001
only.
1
