Serviceable Assemblies: Transducer Plug Replacement Kits
5. Insert the pin housing into the corresponding recess of the half-shell (with
strain-relief mounting holes). Position the housing so that the two dots at the
back are visible and at right angles to the plane of the half-shell. Push the cable
into the strain-relief slot. Ensure the slot surrounds a portion of the cable with
the outer covering intact.
6. Fasten the strain-relief clamp to the half-shell using the two metric screws.
Refer to inset of Figure 7-4.
Tocotransducer: the indent of the strain relief should
face outward.
Ultrasound and FECG Transducers: the indent of the strain relief should
face inward.
7. Place the half-shell (with tongue) on the pin housing, aligning it with the two
dots on the back of the housing. The half-shells should snap together evenly.
Slip the retaining ring over them to hold the assembly together.
8. Slide the gripper back up the cable and align the two projections at the rear of
the plug assembly with the two recesses at the rear of the gripper.
NOTE: Do not allow projections and recesses to become misaligned while
sliding the gripper onto the plug or the gripper will not seat properly.
Position the tongue opposite the gripper boot through which the cable
extends. This ensures that the cable will extend downward once the
plug is inserted into the monitor.
CAUTION
KINKING—When sliding the gripper over the plug assembly,
pull the cable through the boot to prevent any kinking inside the
gripper.
9. Install the plastic ring on the front of the plug.
