Revision C 170 Series Monitor 7-19
2000947-004
Serviceable Assemblies: Removing the Monitor Top Cover
Removing the Monitor Top Cover
1. Unplug the AC adapter from the monitor to completely remove power.
2. Remove the four bottom panel screws.
CAUTION
TOP COVER—The top cover remains tethered to the main
board via the display board and membrane switch panel cables.
Do not attempt to remove the monitor cover without first
disconnecting these cables.
3. Partially lift the top cover and slide it partways back to reveal the cables
connecting to the main board.
4. Disconnect the display board cable from J18 on the main board.
5. Disconnect the membrane switch panel cable from J19 on the main board.
