11-8 170 Series Monitor Revision C

2000947-004

Parts Lists: 2001972-037, Model 173 Final Assembly

2001972-037, Model 173 Final Assembly

Table 11-3. Model 173 Final Assembly, 2001972-037

Find Num Item Number Item Description Qty

1 2007385-001 ENCL ,BOTTOM, SHIELDED-170 SERIES 1

2 15451AA COVER SPEAKER 1

3 140173 FOOT RUBBER .50D .26H 4

4 15222AA BRG DRAWER 2

5 15212AA PIN BEARING-170 2

6 15200A ASSY ROLLER 1

7 250096 BEARING,FLANGED,.187 BORE, 2

8 11717AA ROLLER GEAR-120REC, 1

9 15207A ASSY DRAWER, WELDED 1

10 15224AA SPACER DRAWER 1

11 15223AA PLASTIC 9 CM PARTITION 1

12 15231A ASSY PCB SENSOR BOARD 1

13 2000147-001 SENSOR INSULATOR 170 SERIES 1

14 250099 SPRING COMPRESSION,.24 OD,,.38L 1

15 2000222-001 SPRING CPRSN .3 OD .022WIRE SS 2

16 15136A MOTOR STEPPER ASSY 1

17 15202AA MOUNT MOTOR 1

18 15201AA PLATE PC MOUNTING 1

19 2000133-001 PRINTHEAD 8 DOTS/MM 216MM WIDE 1

20 15203AA PLATE HEAD MOUNTING 1

21 2000223-001 SPRING CPRSN .56L .240 OD .024 WIRE 2

22 15204AA BRACKET HEADSTOP 1

23 2002433-001 STANDOFF 1/4 HEX SWAGE 4-40 2

24 281501 NUT,HEX,4-40,3/32 X 1/4 2

25 2000234-001

CABLE ASSY RIBBON RECORDER 170

SERIES

26 2000235-001 CABLE ASSY SPEAKER WIRE 170 SERIES 1

27 2000146-001 CLIP GROUND 2

28 2000324-007

PCB ASSY MAIN FECG/PRS COMP V3.20-

173
