8-2 170 Series Monitor Revision C
2000947-004
Peripheral Devices: Remote Marks Connectors
Remote Marks Connectors
Remote Mark, Fetal Acoustic Stimulator
This receptacle is provided for connection to a Corometrics Model 146 Fetal
Acoustic Stimulator.
Remote Mark, Remote Event Marker
This receptacle is provided for connection to an optional Corometrics Remote Event
Marker. A Corometrics Remote Event Marker is used to annotate the strip chart
recorder paper with a mark.
The printed mark can be configured as , commonly used to record an “event”; or it
can be configured as , commonly used as an indication that the mother has
perceived fetal movement. The monitor is factory set with the mark configured as
. Refer to “Customizing the Monitor” on page 4-10 for more information on
selecting the mark. Refer to the instructions accompanying the Remote Event
Marker for more information about using the accessory.
FM
FM
