GE Corometrics 170 Series Service Manual

Revision C 170 Series Monitor 11-5
2000947-004
Parts Lists: 2000268-189, Model 172 Final Assembly
2000268-189, Model 172 Final Assembly
Table 11-2. Model 172 Final Assembly, 2000268-189
Item
Number
Part Number Description Qty
1 2000281-001 ENCL BOTTOM SHIELDED 170 SERIES 1
2 15451AA COVER SPEAKER 1
3 140173 FOOT RUBBER .50D .26H 4
4 15222AA BRG DRAWER 2
5 15212AA PIN BEARING-170 2
6 15200A ASSY ROLLER 1
7 250096 BEARING FLANGED .187 BORE 2
8 11717AA ROLLER GEAR-120REC 1
9 15207A ASSY DRAWER WELDED 1
10 15224AA SPACER DRAWER 1
11 15223AA PLASTIC 9 CM PARTITION 1
12 15231A ASSY PCB SENSOR BOARD 1
13 2000147-001 SENSOR INSULATOR 170 SERIES 1
14 250099 SPRING COMPRESSION .24 OD .38L 1
15 2000222-001 SPRING CPRSN .3 OD .022WIRE SS 2
16 15136A MOTOR STEPPER ASSY 1
17 15202AA MOUNT MOTOR 1
18 15201AA PLATE PC MOUNTING 1
19 2000133-001 PRINTHEAD 8 DOTS/MM 216MM WIDE 1
20 15203AA PLATE HEAD MOUNTING 1
21 2000223-001
SPRING CPRSN .56L .240 OD
.024 WIRE
2
22 15204AA BRACKET HEADSTOP 1
23 280201 STANDOFF 1/4HEX 1/8SL 4-4 0 THD 2
24 281501 NUT HEX 4-40 5/64 X 1/4 2
25 2000234-001
CABLE ASSY RIBBON RECORDER
170 SERIES
1
26 2000235-001
CABLE ASSY SPEAKER WIRE
170 SERIES
1
27 2000146-001 CLIP GROUND 2
