11-6 170 Series Monitor Revision C
2000947-004
Parts Lists: 2000268-189, Model 172 Final Assembly
28 15269E
PCB ASSY MAIN PCB
DUAL US COMP
1
29 284105 SCREW #4 PH 1/4L THD FORM 7
30 284072 SCR 4-40 PH 5/16L PHL LL STRIP 29
31 284285
SCR 4-40 FH UNDERCUT 3/16 PHIL 2PS
NYLON PATCH
4
32 289516
SCR M3X5 PH PHIL ZP
W/NYLOK PATCH
4
33 2000220-001 SCR PH #2 1/2L PHIL ZPS PLASTITE 2
34 2000221-001 SCR #4 PH 1/4L TYPE F PHIL ZPS 6
35 2000142-001 SPRING FRONT GROUND 1
36 15301A ASSY PCB DISPLAY BOARD 1
37 15461AA GASKET REAR PANEL 1
38 15453AA PAD PRINT TOP COVER-MODEL 170 1
39 15323AA KYBD MEMBRANE US2 1
40 15324AA LABEL DISPLAY OVERLAY US2 1
41 14943AA CLIP SPEAKER 2
42 2000178-001 PLUG CALL LIGHT 1
43 2000359-001 STANDOFF M-F 440 1IN LG ALUM 1
44 2000246-001 PLUG TELEMETRY 1
46 2000240-001
LABEL CUSTOM REAR PANEL
OVERLAYS 170
1
47 284031 SCR 4-40 BH 1/4 LG SLTD N YLON 2
49 608030 CABLE MOUNT ADHESIVE BACK 2
50 608036 TYRAPS CABLE TIES 2
51 7714AAT
POWER SUPPLY 12V 30W
EXTERNAL SUPPLY
1
52 600028 ASSY LINE CORD IEC 1
55 2000890-001 PACKAGING RIGHT CAP 170 SERIES 1
56 2000891-001 PACKAGING LEFT CAP 170 SERIES 1
57 2000892-001 PACKAGING BOXES 170 SERIES 1
58 2000893-001
PACKAGING SLOTTED TRAY
170 SERIES
1
Table 11-2. Model 172 Final Assembly, 2000268-189 (Continued)
Item
Number
Part Number Description Qty
To Next Page
