Parts Lists: 5700GAX, Button-Style Nautilus Ultrasound Transducer Assembly Parts List (5-ft cord)

5700GAX, Button-Style Nautilus Ultrasound

Transducer Assembly Parts List (5-ft cord)

Table 11-6. 5700GAX, Button-Style Nautilus Ultrasound Transducer Assembly Parts List (5-ft cord)

Find

Num

Item Number Item Description Qty

1 14895A U/S CBL ASSY 5' OB,WATERTIGHT 1

4 15081AA MARKING,CASE BUTTON TOP U/S,WATERTIGHT 1

6 14791A CASE BOTTOM ASSY U/S,WATERTIGHT 1

7 14594AA FLAT SEAL TOCO U/S WATERTIGHT XDCR 1

8 14640AA CABLE MOUNTING NUT TOCO US WATERTIGHT 1

9 284106 SCR,4-40,PH,5/16L,W/SEAL,PHIL,SS,LL 5

10 2008660-001 SCR CAP, TOCO, U/S 4

11 15254AA SCREW CAP FLAT MARING,WATERTIGHT SCUCERS 1

12 7529EA KNOB TOP, NAUTILUS WATERTIGHT TOCO 1

13 281260 SCR SET 2-56 1/8L OVAL PT SS 1

17 8974AA ABD STRAP-BUTTON STYLE BE,LT 1

18 14855AA WARNING TAG CABLES WATERTIGHT 1

19 13658FA LBL,CE,CAUTION IP68,WATERTIGHT XDCR 1

20 440011 LABEL,2.25X.75,SELF-LAM,WHITE 1

22 4991AA ACC PACKER, 1

23 410069 PACK MATERIAL ST 1

24 410113 BAG,AIRCAP, 8 X 11-1/2, 1

25 15265AA SHIPPING LBL, 5700GAX WATERTIGHT XDUCERS 1

31 13434AA LBL,SHIP CRTN CE MARK-VAR 1

32 160103 ADHESIVE,454 0

33 162004 OIL,SILICONE,3ML TUBE 0

34 OBSER-003 ADDENDUM,WATERTIGHT XDCR 1

35 14957AA WARNING LABEL KIT U/S TOCO WATERTIGHT 1

36 14897AA INSTRUCTION SHEET,WATERTIGHT TOCO 1

37 474045 NETWORK,RES,SIP,47 OHM,9,RES 1
