7-12 170 Series Monitor Revision C

2000947-004

Serviceable Assemblies: Transducer Plug Replacement Kits

Table 7-5. FECG Cable Wiring

Pin Number Pin Length Description Wire Color

1 short — —

2 short ECG Enable Blue and #26 AWG Blue Jumper

3 LONG Ground #26 AWG Blue Jumper

4 short — —

5 short — —

6 short LA (red terminal) White/Black

7 short RA (green terminal) White

8 short Shield #26 AWG Green

9 short — —

10 short — —

11 short — —

12 short RL (plate) White/Red
