Peripheral Devices: RS-232 Connectors
NOTE: The interface cables can be used with both 120/2120is and 170 Series
Monitors. Although the 120/2120is uses 6-pin RJ-11 connectors and the
170 uses 8-pin RJ-45 connectors, the latter is center keyed to account for
this. The 170 uses RJ-45 connectors to provide for future interface
features.
Table 8-2. External Device Summary
External Device Parameter(s)
170 Series
Baud Rate
170 Series Mode
Interconnect Cable Cat.
No.
Critikon Model 1846/1846SX NBP 600 ext. BP
1562AAO (1 foot)
1562BAO (6 feet)
Quantitative Sentinel System
Annotations
(optional)
1200 HP or HP w/notes
1558AAO (10 feet)
1558BAO (20 feet)
Nellcor N-400 FSpO
2 2400 ext. FSpO2
1557AAO (1 foot)
1557BAO (6 feet)
