Revision C 170 Series Monitor 11-3
2000947-004
Parts Lists: 2000268-188, Model 171 Final Assembly
28 2000243-004
PCB MAIN SINGLE
U/S COMPLETE
1
29 284105 SCREW #4 PH 1/4L THD FORM 7
30 284072 SCR 4-40 PH 5/16L PHL LL STRIP 29
31 284285
SCR 4-40 FH UNDERCUT 3/16
PHIL 2PS NYLON PATCH
4
32 289516
SCR M3X5 PH PHIL ZP
W/NYLOK PATCH
4
33 2000220-001 SCR PH #2 1/2L PHIL ZPS PLASTITE 2
34 2000221-001 SCR #4 PH 1/4L TYPE F PHIL ZPS 4
35 2000142-001 SPRING FRONT GROUND 1
36 15301A ASSY PCB DISPLAY BOARD 1
37 15461AA GASKET REAR PANEL 1
38 15453CA PAD PRINT,TOP COVER-MODEL175 1
39 15323BA KYBD MEMBRANE US1 1
40 15324BA LABEL DISPLAY OVERLAY US1 1
41 14943AA CLIP, SPEAKER, 2
42 2000178-001 PLUG CALL LIGHT 1
43 2000359-001 STANDOFF M-F 440 1IN LG ALUM 1
44 2000246-001 PLUG TELEMETRY 1
45 2000186-001 PLUG NICOLAY CONN 1
46 2000240-001
LABEL CUSTOM REAR PANEL
OVERLAYS 170
1
47 284031 SCR 4-40 BH 1/4 LG SLTD N YLON 2
49 608030 CABLE MOUNT ADHESIVE BACK 2
50 608036 TYRAPS CABLE TIES 2
51 7714AAT
POWER SUPPLY 12V 30W
EXTERNAL SUPPLY
1
52 600028 ASSY LINE CORD IEC 1
55 2000890-001 PACKAGING RIGHT CAP 170 SERIES 1
56 2000891-001 PACKAGING LEFT CAP 170 SERIES 1
57 2000892-001 PACKAGING BOXES 170 SERIES 1
Table 11-1. Model 171 Final Assembly, 200268-188 (Continued)
Item
Number
Part Number Description Qty
To Next Page
