11-12 170 Series Monitor Revision C
2000947-004
Parts Lists: 2001972-038, Model 174 Final Assembly
29 284105 SCREW #4 PH 1/4L THD FORM 7
30 284072 SCR,4-40,PH,5/16L,PHL,LL,STRIP 33
31 284285
SCR,4-40,FH UNDERCUT 3/16,PHIL 2PS
NYLON PATCH
4
32 289516 SCR,M3X5,PH,PHIL,ZP,W/NYLOK PATCH 4
33 2000220-001 SCR PH #2 ,1/2L PHIL ZPS PLASTITE 2
34 2000221-001 SCR #4 PH 1/4L TYPE F PHIL ZPS 2
35 2001894-001 SPRING FRONT GROUND-173 1
36 15301A ASSY PCB DISPLAY BOARD 1
37 15461AA GASKET REAR PANEL 1
38 2004993-004 PAD PRINT,TOP COVER, MODEL 174 1
39 15323AA KYBD MEMBRANE US2 1
40 15324DA
LABEL DISPLAY OVERLAY FECG MODEL
174
1
41 14943AA CLIP, SPEAKER, ACCESS HOME MONITOR 2
42 2000178-001 PLUG CALL LIGHT 1
43 2000359-001 STANDOFF M-F 440 1IN LG ALUM 1
44 2000246-001 PLUG TELEMETRY 1
45 2000952-001 PCB DUAL U/S FECG-174 1
46 2003930-001 LABEL REAR PANEL 170 SERIES 1
47 284031 SCR,4-40,BH,1/4 LG,SLTD,N,YLON 2
49 608030 CABLE MOUNT,ADHESIVE BACK, 2
50 608036 TYRAPS,CABLE TIES 2
51 7714AAT
POWER SUPPLY 12V 30W EXTERNAL
SUPPLY
1
55 2000890-001 PACKAGING RIGHT CAP, 170 SERIES 1
56 2000891-001 PACKAGING LEFT CAP, 170 SERIES 1
57 2000892-001 PACKAGING BOXES , 170 SERIES 1
58 2000893-001 PACKAGING SLOTTED TRAY, 170 SERIES 1
59 410010 PACKING LIST ENVELOPES, 1
60 2000555-001 SHLD SPEAKER - 170 1
61 410066 POLY BAG 23X26X.006, 1
Table 11-4. Model 174 Final Assembly, 2001972-038 (Continued)
Find Num Item Number Item Description Qty
To Next Page
