4-12 170 Series Monitor Revision C
2000947-004
Setup Procedures: Customizing the Monitor
You can enter the user setup mode during an active monitoring session. The fetal
heart rate and uterine activity trends print without interruption and the FHR tones
remain audible; however you will be unable to see the heart rate and uterine activity
values on the display while in the user setup mode.
You can only enter the service setup mode from a power off state.
NOTE: If an alarm occurs while in user setup mode, the heart rate display will not
flash; however, the alarm indicator flashes and the audio alarm sounds.
As soon as you exit the setup mode, the affected display flashes to indicate
the alarm condition.
1. Enter the appropriate mode, user or service, as follows:
User: To enter the user mode:
Press the monitor’s Power button to turn on the monitor. Wait until
the monitor completes the self-test routine and enters the normal operating
mode.
Press and hold the Setup button , for three seconds, to enter the user
setup mode.
Service: To enter the service mode:
Press and hold the Setup button
Press and hold the blue Power button .
Release both buttons. The service mode is now activated.
2. Use the
UA Reference button to toggle between the setup code (shown in
the UA display) and the setting or value (shown in the primary FHR display).
The UA display is active when the
± qualifier illuminates; the FHR display is
active when the heartbeat indicator
() illuminates.
3. Use the
Volume buttons to increase ( ) or decrease ( ) the code,
value, or setting shown in the active display. Refer to Table 4-2 (user codes) or
Table 4-3 (service codes). (For Models 172, 173, and 174, use the leftmost set
of volume controls.)
4. Repeat steps 2 and 3 until all settings are configured.
5. Press the
Setup button to exit the setup mode. Exiting the user setup
mode returns to the monitoring mode; exiting the service setup mode turns the
monitor to standby.
