2042480-001 C Dash 2500 Patient Monitor 13-13
MASIMO SET® SpO2: Specifications
Specifications
Specifications
Measurement Range
SpO
2
1 to 100%
Pulse Rate 25 to 240 bpm
Perfusion Range 0.02 to 20%
Accuracy and Motion Tolerance
Saturation
Without Motion - Adult/Pediatric* 70 to 100% ±2 digits
Without Motion - Neonate* 70 to 100% ±3 digits
With Motion - Adult/Pediatric/Neo**
† 70 to 100% ±3 digits
Low Perfusion‡ 70 to 100% ±2 digits
0 to 69% unspecified
Pulse Rate
Without Motion 25 to 240 bpm ±3 digits
With Motion normal physiologic range
25 to 240 bpm ±5 digits
* The MASIMO SET
®
SpO
2
parameter with LNOP-Adt sensors has been validated for no motion accuracy in human blood studies on healthy adult
volunteers in induced hypoxia studies in the range of 70-100% SpO
2
against a laboratory co-oximeter and ECG monitor. This variation equals plus
or minus one standard deviation. Plus or minus one standard deviation encompasses 68% of the population.
**The MASIMO
SET
®
SpO
2
parameter with LNOP-Adt sensors has been validated for motion accuracy in human blood studies on healthy adult
volunteers in induced hypoxia studies while performing rubbing and tapping motions at 2 to 4 Hz at an amplitude of 1 to 2 cm and a nonrepetitive
motion between 1 to 5 Hz at an amplitude of 2 to 3 cm in induced hypoxia studies in the range of 70-100% SpO
2
against a laboratory co-oximeter
and ECG monitor. This variation equals plus or minus one standard deviation. Plus or minus one standard deviation encompasses 68% of the
population.
†The MASIMO
SET
®
SpO
2
parameter with LNOP-Neo Pt sensors has been validated for neonatal motion accuracy in human blood studies on
neonates while moving the neonate’s foot at 2 to 4 cm against a laboratory co-oximeter and ECG monitor. This variation equals plus or minus, one
standard deviation. Plus or minus one standard deviation encompasses 68% of the population.
‡The MASIMO
SET
®
SpO
2
parameter has been validated for low perfusion accuracy in bench top testing against a Biotek Index 2 simulator and
MASIMO’s simulator with signal strengths of greater than 0.02% and a % transmission of greater than 5% for saturations ranging from 70 to
100%. This variation equals plus or minus, one standard deviation. Plus or minus one standard deviation encompasses 68% of the population.
NOTE: LNCS sensors using LNCS cable technology offer nearly the same performance as the LNOP flex-circuit
design. The LNOP single patient sensor line is still the industry “gold standard”, while LNCS is the best cabled
sensor alternative.
