2042480-001 C Dash 2500 Patient Monitor 2-9
Product Overview: Specifications
AC Input Voltage 100-240 V
AC Input Frequency 50/60 Hz
AC Input Power 120 VA
Internal Battery 8.4 V nickel-metal-hydride (NiMH)
Power Supply The Dash 2500 Patient Monitor can be powered from the internal battery or AC
power.
Battery An internal, rechargeable battery pack powers the Monitor for greater than 180
minutes at a specified load. The battery typically charges to full capacity within 4
hours when power off.
Power Cable The power cable is detachable.
* The Monitor may not meet Performance Specifications (ANSI/AAMI SP10) if it is stored or used outside of the specified ranges of environmental
parameters.
Fuses
Internal
FS1 0.5 amp, 60V, auto-reset
FS2 1.85 amp, 60V, auto-reset
FS3 10 amp, 250V, fast acting, not resettable
FS4 0.5 amp, 60V, auto-reset
FS5 0.1 amp, 60V, auto-reset
External
FS 1amp, 250V, not resettable
FS 1amp, 250V, not resettable
